BendPak PL-6000DC - Page 90

PL-6000DC/DCX Two-Post Parking Lift 90 P/N 5900273 — Rev. A6 —July 2024
5721032
Release Angle, Safety
Lock
Length ≈75 in.
(1905 mm)
1
5737322
Rocker Arm (only) angled
Safety Release
Mechanism
1
5737323
Rocker Arm, straight
(Safety Release)
2
5216126
Roller for Chain Assm.
(Lift Chain)
1
Assy.
5216127
Roller Assy. (for Balance
Chain) roller, pin, and hex
bolt
1
Assy.
5716082 Slide Blocks 8
5701868
Bracket, Power Unit
Mounting Weldment
1
5602020
PL-6000DC Drive-Up
Weldment
1
