115
6 - Parameter Descriptions
I25: Input Terminal Status Display
Range:
Description: This code displays the input status of control terminals P1-P8.
Current input terminal status (ON/OFF) can be monitored in I25.
•
The following is displayed when P1, P3, P4 are ON and P2, P5 are OFF.
I26: Output Terminal Status Display
Range: BIT1 - BIT0
3AC - MO
Description: This parameter displays the condition of each of the outputs. This is useful
in monitoring the status of the terminals. Current output terminals (MO,
relays) status (ON/Off) can be monitored in I26.
3AC M O
(O N )
(O F F )
Input
T/M
P8 P7 P6 P5 P4 P3 P2 P1
7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Bit
OFF
status
ON
status
Input
T/M
3AC MO
1 Bit 0 Bit
OFF status
ON status
