BENSHAW RSi GX Series User Manual

137
7 - Remote Communication
Address
Code Parameter Initial Value Max. Min.
16 bit 10 bit
A21C 41500 F28 Fwd Boost 20 150 0
A21D 41501 F29 Rev Boost 20 150 0
A21E 41502 F30 VF Pattern 0 2 0
A21F 41503 F31 User Freq 1 1500 Max Freq 0
A220 41504 F32 User Volt 1 25 100 0
A221 41505 F33 User Freq 2 3000 Max Freq 0
A222 41506 F34 User Volt 2 50 100 0
A223 41507 F35 User Freq 3 4500 MaxFreq 0
A224 41508 F36 User Volt 3 75 100 0
A225 41509 F37 User Freq 4 6000 MaxFreq 0
A226 41510 F38 User Volt 4 100 100 0
A227 41511 F39 Volt Perc 1000 1100 400
A228 41512 F40 Energy save 0 30 0
A232 41522 F50 ETH select 0 1 0
A233 41523 F51 ETH 1min 150 200 F52
A234 41524 F52 ETH cont 100 F51 50
A235 41525 F53 Motor type 0 1 0
A236 41526 F54 OL level 150 150 30
A237 41527 F55 OL time 100 300 0
A238 41528 F56 OLT select 1 1 0
A239 41529 F57 OLT level 180 200 30
A23A 41530 F58 OLT time 600 600 0
A23B 41531 F59 Stall prev. 0 7 0
A23C 41532 F60 Stall level 150 150 30
Function Group 1 (F)
Address
Code Parameter Initial Value Max. Min.
16 bit 10 bit
A300 41728 H0 JUMP CODE 1 100 0
A301 41729 H1 Last Fault1 0 1 0
A302 41730 H2 Last Fault2 0 1 0
A303 41731 H3 Last Fault 3 0 1 0
A304 41732 H4 Last Fault 4 0 1 0
A305 41733 H5 Last Fault5 0 1 0
A306 41734 H6 Fault Clear 0 1 0
A307 41735 H7 Dwell freq 500 maxFreq startFreq
A308 41736 H8 Dwell time 0 100 0
A30A 41738 H10 Jump freq 0 1 0
A30B 41739 H11 jump lo 1 1000
JumpHiFreq
[0]
startFreq
Function Group 2 (H)
