BENSHAW RSi GX Series User Manual

136
7 - Remote Communication
Address
Code Parameter Initial Value Max. Min.
16 bit 10 bit
A100 41216 D00 Command Frequency 0 Max. Freq 0
A101 41217 D01 ACC 50 60000 0
A102 41218 D02 Dec 100 60000 0
A103 41219 D03 DRV 1 3 0
A104 41220 D04 FRQ 0 8 0
A105 41221 D05 ST 1 1000 Max Freq 0
A106 41222 D06 ST 2 2000 Max Freq 0
A107 41223 D07 ST 3 3000 Max Freq 0
A108 41224 D08 CUR 0 1 0
A109 41225 D09 RPM 0 1800 0
A10A 41226 D10 DCL 0 65535 0
A10B 41227 D11 USR 0 1 0
A10C 41228 D12 FLT 0 1 0
A10D 41229 D13 DRC 0 1 0
A10E 41230 D14 DRV2 1 2 0
A10F 41231 D15 FRQ2 0 6 0
Drive Group
Address
Code Parameter Initial Value Max. Min.
16 bit 10 bit
A201 41473 F1 Run Prohibit 0 2 0
A202 41474 F2 ACC Pattern 0 1 0
A203 41475 F3 DEC Pattern 0 1 0
A204 41476 F4 Stop Method 0 2 0
A208 41480 F8 DcBr Freq 500 6000 Start Freq
A209 41481 F9 DcBlk Time 10 6000 0
A20A 41482 F10 DcBr Value 50 200 0
A20B 41483 F11 DcBr Time 10 600 0
A20C 41484 F12 DcSt value 50 200 0
A20D 41485 F13 DcSt Time 0 600 0
A20E 41486 F14 PreEx Time 10 600 0
A214 41492 F20 Jog Freq 1000 Max Freq 0
A215 41493 F21 Max Freq 6000
Freq High
Limit
4000
A216 41494 F22 Base Freq 6000
Freq High
Limit
3000
A217 41495 F23 Start Freq 50 1000 0
A218 41496 F24 Freq Limit 0 1 0
A219 41497 F25 High Freq 6000 Max Freq 0
A21A 41498 F26 Low Freq 50 High Freq Start Freq
A21B 41499 F27 Trq Boost 0 1 0
Function Group 1 (F)
