Product Description BERGHOF Automation
16 DC1000_HB_en_2D0982003ZD00.doc 2VF100107FE03.doc
E-bus extension The DIALOG CONTROLLER’s I/O level can be expanded via the E-bus socket to
include up to seven E-bus subscribers.
Expansion slots The device is equipped with three expansion slots for expansion cards (e.g., I/O
cards) with the associated SPI interface. Alternately, one of the slots can be used
for an “Anybus
®
” embedded bus module (e.g., Profibus DP) manufactured by
HMS.
Real-time clock A software interface can be used to set or reset a real-time clock equipped with a
backup battery.
SD card reader Data can be written to or read from memory cards using the conventional MMC/SD
card interfaces.
If the SD card reader is activated, then the second RS232 interface (X5) is not
longer available.
Performance feature overview
• Freescale POWERPC
TM
CPU: 266 (400) MHz
• Application program and data memory(RAM):
64 (128) MB onboard / 32 (96) MB for the application
• Application program memory (Flash):
16 (32) MB onboard / 8 (24) MB for the application
• Retain memory: 16 KB
• 1 Ethernet 10/100 port
• 2 (3) USB host ports
• 2 CAN ports
• 1 RS232 serial port for programming tools and applications
• 2 serial data ports: RS232 / RS485
• I/O level locally expandable via an internal E-bus for up to seven subscribers
(digital / analog)
• 3 onboard expansion slots for I/Os and a bus module
• Real-time clock
• MMC /SD card slot
Standard delivery The controller module’s standard delivery includes:
• DIALOG CONTROLLER DC1000.
