5.1.1. Technical Specifications
Module data
Versions / part no. Only available as a built-in module
Dimensions, WxH [mm] 113.5 x 108
Weight approx. 100 g
Operating temperature range 5° C to 50° C (condensation free) Convection cooling ensured
EMI, protection class, insulation test, protection type (installed)
Interference emission EN 61000-6-4, Industrial application
Interference resistance EN 61000-6-2, Industrial application
Protection class III
Insulation resistance EN 61131-2; DC 500 V test voltage
Protection type IP 20
Supply voltage, current consumption
Module electronics power supply
(connection voltage)
SELV DC +24 V < 0.4 A (EN 61131-2)
Digital I/O power supply DC +24 V (EN 61131-2) together with module supply
Current consumption
At U
e
= DC +24 V in neutral, max. 500 mA,
Fusing based on I/O load, max. 8 A
Protection against supply voltage
pole reversal
Yes
Potential isolation No
Digital inputs/outputs (DIO)
Number of inputs
12 (X1/X2), of which 4 can be used as +24V encoder inputs;
counter frequency at 4x evaluation: < 20 kHz
Number of outputs 8 (X9)
Number of inputs/outputs 4 (X2)
Output current 0.5 A
Short circuit protection Yes
Potential isolation Yes
Connection technique Standing front wiring for 3.81 terminal strips (not part of the standard delivery)
Analog inputs
Number 2 analog inputs, 0..20mA / 0..10V switchable (X10/X13)
Input characteristics Up to 20 mA U < 5V in case of short circuit, max. 40 mA
Resolution 10 Bit (accuracy: 8 Bit)
Connection technique Standing front wiring for 3.81 terminal strips (not part of the standard delivery).
CAN interfaces
Number and type of interfaces
1 CAN interface for (X20) contact line communications / SC_CAN (X3);
1 SC_CAN monitoring interface with standard signals
Connection technique Standing front wiring for 3.81 terminal strips (not part of the standard delivery).
Operating and display elements
Display elements
Interface (X11) for 5-place, 7-segment display with IR receiver diode for re-
mote control.
