Extension Modules BERGHOF Automation
72 DC1000_HB_en_2D0982003ZD00.doc 2VF100124FE01.doc
5.2.1. Technical Specifications
Module data
Versions / part no. Only available as a built-in module
Dimensions, WxHxD [mm] 56.5 x 108 x 8
Weight approx. 100 g
Operating temperature range 5° C to 50° C (condensation free) Convection cooling ensured
EMI, protection class, insulation test, protection type (installed)
Certification CE, UL, cUL
Interference emission EN 61000-6-4, Industrial application
Interference resistance EN 61000-6-2, Industrial application
Protection class III
Insulation resistance EN 61131-2; DC 500 V test voltage
Protection type IP 20
Supply voltage, current consumption
Module electronics power supply
(connection voltage)
5 V / max. 370 mA from the DIALOG CONTROLLER’s mains power supply
PROFIBUS MASTER interfaces
Number and type of interfaces
1 PROFIBUS MASTER DP interface,
for connecting a max. of 125 slave nodes.
Potential isolation Yes
Connection technique 9-pin, Sub-D
Operating and display elements
Display elements 4 diagnostic LEDs
