BERGHOF DC1005 - DC1010 Technical Specifications

Product Description BERGHOF Automation
24 DC1000_HB_en_2D0982003ZD00.doc 2VF100107FE03.doc
2.4. Technical Specifications, DC1010
DIALOG CONTROLLER
Product identification
Display type: Input: Designation: Part no.:
Color TFT Keyboard DC1010T K MP400 270000800
Color TFT Touchpad DC1010T T MP400 270000400
Display
Diagonal measurement 10.4”
Resolution 640 x 480 pixels (VGA)
Colors 65536 (16 bit per pixel)
CPU, application memory
CPU Freescale PowerPC 400 MHz
Program memory (Flash) 32 MB onboard / 24 MB for the application
Program memory and data memory
(RAM)
128 MB onboard / 96 MB for the application
Retain memory 16 KB
Real-time clock Yes
Development environment CP1131 (CoDeSys 2.3)
Dimensions and weights
Dimensions (WxHxD [mm]) 360 x 260 x 77 (+6 mm front panel)
Weight approx. 5 kg
Operating conditions
Ambient temperature range 0°C to 50°C
Relative humidity max. 90 %, non-condensing
Transport, storage
Ambient temperature range -20°C to +70°C
Relative humidity max. 90 %, non-condensing
Shock resistance
Vibration Sinusoidal (EN 60068-2-6) test: Fc
10 ... 150 Hz, 1 G (operation mode)
Shock resistance
15 G (approx. 150 m/s²); duration: 10 ms; semi-sinusoidal (EN 60068-2-27)
test: Ea
EMC, protection type
Interference emission EN 61000-6-4, industrial environments
Interference resistance EN 61000-6-2, industrial environments
Protection class III
Insulation resistance EN 61131-2; DC 500 V test voltage
Protection type IP20 (front IP65)
