2.1. Identification
Product DIALOG CONTROLLER
Type DC10xx
Identification key The identification code provides a key to the DIALOG CONTROLLER (refer to the
nameplate). The code can be read as follows.
2VF100227DG01_en.cdr
Nameplate
2VF100228DG01_en.cdr
DC1005C T MP 66
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
...
05
10
12
15
=
= 10,4”
= 12,1”
= 5,0”1
5,7”
M
=
= Color (CSTN)
= Color TFT
C
T
Monochrome (STN)
T
K
= Touchpanel
= Keyboard
MP266
MP400
= Power PC 266 MHz
= Power PC 400 MHz
Screen size
(diagonal)
Activation method
Processor type
Manufacturer’s production date code
