5.3.2. Front View and Pin Assignment
Pin overview
2VF100310DG00.cdr
Power supply
External power supply The PROFIBUS SLAVE communications interface is supplied from the DIALOG
CONTROLLER's power supply.
Installation
The PROFIBUS SLAVE card is factory installed and may only be installed in the
DIALOG CONTROLLER in the position shown in the figure below.
2VF100311DG00.cdr
Indicators
S1
S3
S2
Address x1
Termination
ON OFF
A
ddress x10
X1
Profibus
DC Profibus-DPS
Online Offline
n.c. Error1
2 3
4
