BERGHOF Automation Extension Modules
2VF100124FE01.doc DC1000_HB_en_2D0982003ZD00.doc 65
Digital input data
Module data
Number of inputs 12 (max. 16 if the I/O is used as an
input)
Line length:
in the circuit cabinet
field wiring
Take the voltage drop into account
when selecting a conductor. Other
than this, there are no relevant re-
strictions.
Comply with all locally applicable re-
quirements as well as those in ac-
cordance with EN 61131-3.
Where the risk of lightning exists,
please consult the manufacturer.
Nominal load voltage, L+
Pole reversal protection
DC 24 V (SELV)
Yes
Potential isolation Yes (optocoupler) in groups
Status indicator None
Alarms Definable depending on the software
Input delay Definable via the software
Input capacitance < 10 nF
