PROFIBUS MASTER interface
The embedded PROFIBUS MASTER bus module is a PROFIBUS DP master.
The module has been tested for conformity with the PROFIBUS standard and for
inter-operability with many leading PROFIBUS slave devices. The onboard micro-
processor automatically performs all PROFIBUS bus traffic thus completely reliving
the automation device’s main processor of any PROFIBUS protocol processing.
The PROFIBUS MASTER module supports a max. of 125 slaves with up to 3 KB of
I/O data. All baud rates from 9.6 KB/sec. to 12 MB/sec. can be set. All cyclic
PROFIBUS DP services are available.
PROFIBUS-X2
(jack) Pin assignment of the galvanically isolated field bus interface
Pin Signal Description
1
N.C. Do not connect
2
N.C. Do not connect
3
B RS485 signal
4
RTS Ready to send
5
GND Bus ground
6
+5V Bus (output)
7
N.C. Do not connect
8
A RS485 signal
9
N.C. Do not connect
Diag. – X1
(pins) Pin assignment, serial diagnostics interface
Pin Signal Description
1
N.C. Do not connect
2
RxD RS232 signal
3
TxD RS232 signal
4
N.C. Do not connect
5
GND Bus ground
6
N.C. Do not connect
7
N.C. Do not connect
8
N.C. Do not connect
9
N.C. Do not connect
All application and diagnostic data are set up via the CoDeSys controller configu-
ration or are provided by the application. Therefore, the diagnostic interface can-
not be used in an application-specific manner.
