Extension Modules BERGHOF Automation
68 DC1000_HB_en_2D0982003ZD00.doc 2VF100124FE01.doc
Digital output data
Module data
Number of outputs 8 (max. 12 if the I/O is used
as an output)
Type of output Semiconductor, non-saving
Protected circuit for inductive loads Quick deactivation
50 V terminal voltage (typical)
against + 24 V
Power dissipation resulting from deactiva-
tion
max. 0.5 W / output
max. 4 W / module
Status indicator None
Diagnostic function None
Load connection
Total load (100%) 6 A (12 x 0.5 A)
Overload protection Yes,
for thermal overloads
Activation of the thermal overload pro-
tection may influence adjacent out-
puts.
Short circuit protection
1)
Activation threshold
Yes, electronic current limiter
min. 0.5 A, typically 0.9 A
1) Current is electronically limited. Activation of the short circuit protection results in a thermal
overload which activates the thermal overload protection.
Output delay
From “0” to “1”
From “1” to “0”
max. 0.5 ms
max. 0.5 ms
Output capacitance < 20 nF
Reference voltage
Voltage drop (at reference current)
DC +24 V
< 0.5 V
Reference current
for “1” signal
Leakage current
for “0” signal
0.5 A
max. 0.1 mA
Total current, all outputs
(horizontal installation on vertical panel)
max. 6 A (12 x 0.5)
Lamp load (DC +24 V) max. 6 W
Parallel switching of two outputs
for logical linkage
to increase performance
Permissible
Prohibited
Insulation resistance
Reference voltage 0 V <Ue <50 V
Test voltage up to an altitude of 2000 m DC 500 V
