2.3. Technical Specifications, DC1005
DIALOG CONTROLLER
Product identification
Display type: Input: Designation: Part no.:
Monochrome (STN) Keyboard DC1005M K MP266 270000100
Monochrome (STN) Touchpad DC1005M T MP266 270000000
Color (CSTN) Touchpad DC1005C T MP266 270000200
Color TFT Touchpad DC1005T T MP266 270000300
Color TFT Keyboard DC1005T K MP266 270000900
Display
Diagonal measurement 5.7”
Resolution 320 x 240 pixels (1/4 VGA)
Colors
Monochrome (STN): 4
Color (CSTN): 256 (8 bits per pixel)
Color TFT 256 (8 bits per pixel)
CPU, application memory
CPU Freescale PowerPC 266 MHz
Program memory (Flash) 16 MB onboard / 8 MB for the application
Program memory and data memory
(RAM)
64 MB onboard / 32 MB for the application
Retain memory 16 KB
Real-time clock Yes
Development environment CP1131 (CoDeSys 2.3)
Dimensions and weight
Dimensions (WxHxD [mm]) 194 x 172 x 52 (+6 mm front panel)
Weight approx. 1.5 kg
Operating conditions
Ambient temperature range 0°C to 50°C
Relative humidity max. 85 %, non-condensing (monochrome: max. 75 %)
Transport, storage
Ambient temperature range -20°C to +70°C
Relative humidity max. 85 %, non-condensing (monochrome: max. 75 %)
Shock resistance
Vibration
Sinusoidal (EN 60068-2-6) test: Fc
10 ... 150 Hz, 1 G (operation mode)
Shock resistance
15 G (approx. 150 m/s²); duration: 10 ms; semi-sinusoidal (EN 60068-2-27)
test: Ea
EMC, protection type
Interference emission EN 61000-6-4, industrial environments
Interference resistance EN 61000-6-2, industrial environments
Protection class III
Insulating resistance EN 61131-2; DC 500 V test voltage
Protection type IP20 (front: IP65)
