Power supply (24 V power pack)
Supply voltage
+24 VDC (-15% / +20%) SELV
max. alternating component: 5%
Current consumption
Typically 1.0 A; max. 2.0 A at +24 VDC
Fusing depending on the I/O load, max. 12A
Polarity reversal protection Yes
Potential isolation Yes, between CAN bus and I/Os
Ethernet port
Number / interface type 1x 10/100 Base T
Connection method RJ45
USB ports
Number / interface types
1 x host USB, Rev. 1.1 (on rear)
1 x host USB, Rev. 1.1 (on front)
Plug/unplug cycles
max. 1000
CAN bus ports
Number / interface types 2x standard CAN ISO 11898
Potential isolation CAN0 (X6) potential isolated
Transmission rate max. 1 MBit/s
Terminating resistor Switchable
Serial port
Number / interface types
2x RS232
1x RS485
Potential isolation RS485 (X8) potential isolated
Terminating resistor Switchable with the RS485
E-bus port
Interface types I/O expansion bus for up to 7 E-bus subscribers
Expansion slots
Number / interface types
3 slots for 3 I/O modules
or
2 I/O modules and one AnyBus
®
module
