Extension Modules BERGHOF Automation
80 DC1000_HB_en_2D0982003ZD00.doc 2VF100124FE01.doc
Indicator LEDs For diagnostic LEDs indicate the current operating state and any error messages.
Indicator Signal Description
1 N.C. Not used
Green: Online / data exchange permitted
2 Online
Off: Not online
Red: Offline, no data exchange possible 3 Offline
Off: Not offline
Red, flashing at
1Hz:
Configuration error; initialized data length
does not match configuration
Red, flashing at
2Hz:
Missing user parameter; initialized data
length does not match configuration
Red, flashing at
4Hz:
Initialization error in the ASIC
4 Error
Off: No diagnostic data available
