Sewing preparation
35
2.6 Slide-on table
Using the slide-on table
When attached to the free arm, it expands the already existing sewing area.
> Raise the needle.
> Raise the presser foot.
> Switch the machine off and disconnect it from the power supply system.
> Push the slide-on table to the right over the free arm until it engages.
> To remove the slide-on table, pull the slide-on table over the free arm to the left.
2.7 Presser foot
Adjusting the presser foot position via the knee lifter of the Free Hand System
> Adjust the sitting height so that the knee lifter can be operated with the knee.
> Push the knee lifter with the knee to the right to raise the presser foot.
– Simultaneously the feed dog is lowered and the thread tension is released.
> Release the knee lifter slowly to lower the presser foot.
