- 26 -
Control unit
EN
Par Function Settable data
Selects the functioning logic.
(see notes after the table)
: Hold-to-run
: Semi automatic
: Automatic
Close input con guration (see
notes after the table)
: Standard close input
: Close-when-released input
: The close command acts as a release closing and safety function.
Photocells
: During closure, it reopens and waits for the photoelectric cell free com-
mands.
: When closing it reopens; reclosing after 1’’ when the photocell is disen-
gaged
: When closing it reopens; reclosing after 5’’ when the photocell is disen-
gaged
Obstacle detection
(for GRIZZLY / OAK 800.4 only)
: Disabled
: When closing it stops and waits for commands
: When closing it reopens and waits for commands
: When closing it reopens, reclosing after 5 seconds
Warning ash
Bollard lights
: Cover lights ashing during movement, cover lights xed when the
bollard is opened and closed
: Cover lights ashing during movement and with bollard open, cover
lights xed when the bollard is closed
: Cover lights always ashing
: Cover lights ashing during movement and with bollard closed, cover
lights xed when the bollard is open
Buzzer
: Buzzer o
: Buzzer on during movement
Resetting default parameters.
(see notes after the table)
: No resetting
: Resetting the default parameters.
: Default parameter reset and con guration of installation type A pa-
rameters (see chapter 12.1)
: Default parameter reset and con uration of installation type B param-
eters (see chapter 12.2)
: Default parameter reset and con guration of installation type C param-
eters (see chapter 12.3)
: Default parameter reset and con guration of installation type D pa-
rameters (see chapter 12.4)
Pause time
(expressed in seconds)
-
Exiting the menu/saving
Exit programming and view machine statuses (see notes St automation
statuses display)
ENGLISH
7.2
1st LEVEL
PROGRAMMING
The following table gives the 1st level functions and the single settable parameters.
= DEFAULT value set in factory.
= parameter value set during installation: must be indicated if
DEFAULT value is modi ed.
Description of level 1 parameters
· : Functioning logic
- Hold-to-run: Close functions active for as long as control buttons are pressed. Open functions activated by pressing and releasing
control buttons. The start command opens once and closes once.
- Semi automatic: The automation works with jog commands, without automatic reclosing. Hence, when fully open, to control closing
you need to act on the start or close command respectively.
- Automatic: The automation works in jogs. When the opening manoeuvre is completed in the standard cycle, automatic reclosing is
activated after the pause time set (parameter ).
