BIFFI ICON3000 User Manual

March 2021
Installation, Operation and Maintenance Manual
MDE 254 Rev. 1
HART Command Set22
Section 8: HART Command Set
Table 42. Response Data Bytes
Byte Format Description
0 - 2 Unsigned-24 Transducer Serial Number
3 Enum Transducer Limits and Minimum Span units Code (see Section 8.4, Table 120)
4 - 7 Float Upper Transducer Limit
8 - 11 Float Lower Transducer Limit
12 - 15 Float Minimum Span
Code Class Description
0 Success No Command-Specific Errors
1 - 15 Undefined
16 Error Access Restricted
17 - 31 Undefined
32 Error Busy
33 - 127 Undefined
Table 43. Command-Specific Response Codes
8.1.13 Command #15: Read Device Information
This command reads the alarm selection code, transfer function code, range values units code,
upper range value, Primary Variable lower range value, damping value and write protect code.
Table 44. Request Data Bytes
Table 45. Response Data Bytes
Byte Format Description
None
Byte Format Description
0 Enum PV Alarm Selection Code (see Section 8.4, Table 122)
1 Enum PV Transfer Function Code (see Section 8.4, Table 121)
2 Enum PV Upper and Lower Range Values Units Code (see Section 8.4, Table 120)
3 - 6 Float PV Upper Range Value
7 - 10 Float PV Lower Range Value
11 - 14 PV Damping Value (units of seconds)
15 Enum Write Protect Code (see Section 8.4, Table 123)
16 Enum Reserved. "250"
17 Bits PV Analog Channel Flags (see Section 8.4, Table 132)
8.1.12 Command #14: Read Primary Variable
Transducer Information
This command reads the Transducer Serial Number, Limits / Minimum Span Units Code, Upper
Transducer Limit, Lower Transducer Limit, and Minimum Spar for the Primary Variable Transducer.
Table 41. Request Data Bytes
Byte Format Description
None
