B.2 Multiple Functionality of Interlock
Command and Status
In case of ICON actuator, the Interlock command can assume the meaning of PST signal, based on
type of actuator and setting of “interlock mode” parameter.
The following Table explicit its functionality:
Table B-2.
ACTUATOR INTERLOCK MODE INTERLOCK COMMAND FUNCTIONALITY
ICON STANDARD INTERLOCK
ICON ADVANCED PST
EFS STANDARD INTERLOCK
EFS ADVANCED INTERLOCK
The “interlock mode” parameter is available on restricted menu, accessible with manufacturer
login access.
