BIFFI ICON3000 User Manual

Installation, Operation and Maintenance Manual
MDE 254 Rev. 1 March 2021
HART Command Set 35
Section 8: HART Command Set
Code Class Description
13 Error Invalid Burst Trigger Mode Selection Code
14 - 15 Undefined
16 Error Access Restricted
17 - 31 Undefined
32 Error Busy (A Delayed Response could not be initiated)
33 Error Delayed Response Initiated
34 Error Delayed Response Running
35 Error Delayed Response Dead
36 Error Delayed Response Conflict
37 - 127 Undefined
8.2.7 Command #105: Read Burst Mode Configuration
This command reads the Burst Mode configuration from the field device including: the Burst Mode
Control Code, the command to be burst and a list of the Device Variables to be transmitted, the burst
minimum and maximum update time and he condition for the maximum update time.
Table 96. Request Data Bytes
Table 97. Response Data Bytes
Byte Format Description
0 Unsigned-8 Burst Message
Byte Format Description
0 Unsigned-8 Burst Mode Control Code (see Section 8.4, Table 125)
1 Unsigned-8 Command Number of the response message to be transmitted
2 Unsigned-8 Device Variable Code assigned to Slot0 (see Section 9.1)
3 Unsigned-8 Device Variable Code assigned to Slot1 (see Section 9.1)
4 Unsigned-8 Device Variable Code assigned to Slot2 (see Section 9.1)
5 Unsigned-8 Device Variable Code assigned to Slot3 (see Section 9.1)
6 Unsigned-8 Device Variable Code assigned to Slot4 (see Section 9.1)
7 Unsigned-8 Device Variable Code assigned to Slot5 (see Section 9.1)
8 Unsigned-8 Device Variable Code assigned to Slot6 (see Section 9.1)
9 Unsigned-8 Device Variable Code assigned to Slot7 (see Section 9.1)
10 Unsigned-8 Burst Message
11 Unsigned-8 Total Number of Burst Messages
12 - 15 Time Update Time in 1/32 of a millisecond
16 - 19 Time Maximum Update Time in 1/32 of a millisecond
20 Enum Burst Trigger Mode Code (see Section 8.4, Table 133)
21 Enum Device Variable Classification for Trigger Value (see Section 8.4, Table 131)
22 Enum Units Code (see Section 8.4, Table 120)
23 - 26 Float Trigger Value
Code Class Description
0 Success No Command-Specific Errors
1 - 5 Undefined
6 Error Device-Specific Command Error
7 - 8 Undefined
9 Error Invalid Burst Message
10 - 31 Undefined
32 Error Busy
33 - 127 Undefined
Table 98. Command-Specific Response Codes
