BIFFI ICON3000 User Manual

Installation, Operation and Maintenance Manual
MDE 254 Rev. 1 March 2021
Device Variables 45
Section 9: Device Variables
Section 9: Device Variables
9.1 List of Device Variables
Table 135.
Dev. Var. Description Classification Unit Code R/W Min Max Type
0 Commands Not Classified None W 0 ENUM_BIT
1 Status 1 Not Classified None R 0 ENUM_BIT
2 Status 2 Not Classified None R 0 ENUM_BIT
3 Position Request Valve Actuator Percent W 0.0 100.0 FLOAT
4 Dead Band Valve Actuator Percent RW 0.1 25.5 FLOAT
5 Motioh Inhibit Time Time Seconds RW 1 255 FLOAT
6 Alarms 1 Not Classified None R 0 ENUM_BIT
7 Alarms 2 Not Classified None R 0 ENUM_BIT
8 Warnings Not Classified None R 0 ENUM_BIT
9 Act. Log - Opening Time Time Seconds R 0 65535 FLOAT
10 Act. Log - Closing Time Time Seconds R 0 65535 FLOAT
11 ESD Action Valve Actuator None RW 0 4 ENUM
12 ESD Percent Valve Actuator Percent RW 0 100 FLOAT
13 2 Speed Timer - Close Dir. Status Valve Actuator None RW 0 1 ENUM
14 2 Speed Timer - Close Dir. Start Pos. Valve Actuator Percent RW 0 100 FLOAT
15 2 Speed Timer - Close Dir. Stop Pos. Valve Actuator Percent RW 0 100 FLOAT
16 2 Speed Timer - Close Dir. On Time Time Seconds RW 2 200 FLOAT
17 2 Speed Timer - Close Dir. Off Time Time Seconds RW 1 200 FLOAT
18 2 Speed Timer - Open Dir. Status Valve Actuator None RW 0 1 ENUM
19 2 Speed Timer - Open Dir. Start Pos. Valve Actuator Percent RW 0 100 FLOAT
20 2 Speed Timer - Open Dir. Stop Pos. Valve Actuator Percent RW 0 100 FLOAT
21 2 Speed Timer - Open Dir. On Time Time Seconds RW 2 200 FLOAT
22 2 Speed Timer - Open Dir. Off Time Time Seconds RW 1 200 FLOAT
23 Fail Safe Action Valve Actuator None RW 0 4 ENUM
24 Fail Safe Delay Time Seconds RW 0 255 FLOAT
25 Fail Safe Position Valve Actuator Percent RW 0 100 FLOAT
26 Power Supply Type Valve Actuator None R 0 2 ENUM
27 Power Supply Voltage EMF Volts R 10 1000 FLOAT
28 Power Supply Frequency Frequency Hertz R 50 60 FLOAT
244 Percent Range Not Classified Percent R 0 100 FLOAT
245 Loop Current Not Classified mA R FLOAT
246 PV - Position Request Not Classified Percent R 0.0 100.0 FLOAT
247 SV - Actuator Position Not Classified Percent R 0.0 100.0 FLOAT
248 TV - Torque Not Classified Percent R -127 128 FLOAT
249 QV - Temperature Temperature Celsius R -127 128 FLOAT
It's not possible to map dynamic variables.
