Installation, Operation and Maintenance Manual
MDE 254 Rev. 1 March 2021
Device Variables 49
Section 9: Device Variables
9.5 Device Variable 2: Actuator Status (2)
This variable describes the status of the actuator. It’s a bit_enumerated variable,
it’s not possible to write this data. The possible values are:
Table 138.
Bit Description
b0 Reserved
b1 Local Configuration
b2 Reserved
b3 Reserved
b4 Reserved
b5 Close Travel Available
b6 Open Travel Available
b7 Reserved
b8 Pos >= xx
b9 Pos <= yy
b10 Reserved
b11 Reserved
b12 Reserved
b13 Reserved
b14 Reserved
b15 Reserved
b16 Intermediate Position
b17 Interlock in Progress
b18 Moving
b19 Alarms
b20 Warnings
b21 Reserved
b22 Reserved
b23 Reserved
b24 Reserved
b25 Reserved
b26 Reserved
b27 Reserved
b28 Reserved
b29 Reserved
b30 Reserved
b31 Reserved
