Big Backyard F23210 - Page 47

 47 support@cedarsummitplay.com
E:Ontheoutsideoftheassemblyplace1(1941)WaterSandSupportoverlappingBrookridgeTarpby1”and
ushtotheoutsideedgesofboth(1931)Posts.Makesuretheboardislevelthenattachwith4(S3)#8x2-1/2”
WoodScrews.(g.28.3)
F:Attach(2028)CafeToptighttothetopof(1941)WaterSandSupportwith3(S7)#12x2”PanScrews.Make
surethenotchededgesaretighttotheposts,.(g.28.3)
G:Fromtheinsideoftheassemblyand1/2”infromtheedgeofthetarp,attachtarpto(2036)CafeGroundand
(1941)WaterSandSupportwith4evenlyspaced(S5)#8x1/2”PanScrews(with#8atwasher)perboard.The
distancebetweenscrewsshouldbe8”.(g.28.4)
H:Tighenthepreviouslyloosenedbolts.
Wood Parts
Hardware
Step 28: Cafe Wall Assembly
Part 2
4 x #8 x 2-1/2” Wood Screw
8 x #8 x 1/2” Pan Screw (#8 at washer)
3 x #12 x 2” Pan Screw
S3
1 x Cafe Top 5/4 x 4 x 35-7/8”
1 x Water Sand Support 2 x 2 x 35-7/8”
2028
1941
S7
S5
Fig. 28.3
1931
OutsideFortView
Fig. 28.4
S7
2028
2036
1931
1941
15”
S3
S3
2036
1941
S5
8”
8”
8”
InsideFortView
S5
