Overview of the current settings
You can check the current settings of the safety controller:
Fixed value
08.03.2015 05:05:06
Submenu “Safety controller”
(view with standard chamber equipment)
Select “Show settings”
and press the operating button.
..\ Safety controller
Mode
Setpoints
Show settings
Close Home
The overview display shows the set-points and actual values of the main temperature controller and the
safety controller and indicates the safety controller mode.
Fixed value
08.03.2015 05:05:06
Overview display with safety controller mode “Limit”
(example values).
In case of a temperature safety device class 3.1
combined with optional chamber equipment, “Safety
controller” is indicated as “Overtemperature” in-
stead.
Setpoint
Actual
Chamber temperature [°C]
37.0
37.6
Safety controller mode
Limit (absolute)
Safety controller [°C]
40.0
37.6
Close
Home
Fixed value
08.03.2015 05:05:06
Overview display with safety controller mode “Off-
set” (example values).
In case of a temperature safety device class 3.1
combined with optional chamber equipment, “Safety
controller” is indicated as “Overtemperature” in-
stead.
Setpoint
Actual
Chamber temperature [°C]
37.0 37.6
Safety controller mode Offset (relative)
Safety controller [°C]
3.0 37.6
Close
Home
Go back to the initial view with “Home”.
