Binder KB 720 (E6) - Chamber Overview

To Next Page

To Previous Page

KB (E4 + E6) 02/2017 page 15/148

2.1 Chamber overview

Instrument panel with microprocessor

controller T4.12 and USB interface

Door handle

Chamber door

Refrigerating module

Main power switch (1)

Figure 4: Cooling incubator KB 53 / 115 (E4)

Instrument panel with microprocessor

controller T4.12 and USB interface

Door handle

Chamber door

Refrigerating module

Lateral control panel with main power

switch and connections

Figure 5: Cooling incubator KB 240 / 400 / 720 (E6)
