7. Configuration of optional equipment
The “Optional equipment” menu item is visible only with optional chamber equipment.
To access the selection menu, go to Menu > Optional equipment
Fixed value
08.03.2015 05:05:06
Submenu “Optional equipment”.
Select the desired function
and press the operating button.
..\ Optional equipment
Interior socket
Zero-voltage relay control outputs
Functional test – alarm output
Object temperature display
RS 422 address
Close Home
7.1 Turning on / off the optional interior socket
For chambers equipped with the water-protected interior socket (option, chap. 19.8) you can turn on and
off the voltage of the interior socket via the controller.
To access the setting menu, go to Menu > Optional equipment > Interior socket
Fixed value
08.03.2015 05:05:06
Submenu “Interior socket”.
The current setting is indicated.
To change the setting,
press the operating button.
The modified setting is displayed.
“Interior socket: Off” = socket voltage-free
“Interior socket: On” = socket with activated voltage
..\ Interior socket
Interior socket: Off
Close Home
Go back to the initial view with “Home”.
This symbol on the controller display indicates that the interior socket is activated.
