Binder KB 720 (E6) - Page 57

KB (E4 + E6) 02/2017 page 57/148
Entering the set-point values for another parameter (fan speed)
The number of program lines (program sections) equal to the number in the temperature program is dis-
played. The settings of section length, repeats and the selection „Ramp“ or „Step“ are taken over from the
temperature program; they are no editable in this view. The symbol “ *** ” indicates that there are no tol-
erance value required for the fan speed. You can enter the fan speed set-points.
If you want to insert further sections or perform any other programming, first change back to
the temperature program through Menu > Select parameter > Temperature controller.
Fixed value
08.03.2015 05:05:06
Time program editor (example).
To edit the values, press the operating button, select
the desired value and press the operating button
again.
..\ Fan speed
[%]
No.
Value
H:M:S
Ref.
Rep.
T. min
T.max
R/S
1
100.00
00:30:00
1
0
***
***
Ramp
1
100.00
00:10:00
1
0
***
***
Ramp
1
100.00
00:30:00
2
3
***
***
Ramp
1
100.00
00:00:01
1
0
***
***
Ramp
Menu
Entering the fan speed setpoint
Fixed value
08.03.2015 05:05:06
Time program editor.
Select a value under “Value”
and press the operating button.
..\ Fan speed
[%]
No.
Value
H:M:S
Ref.
Rep.
T. min
T.max
R/S
1
100.00
00:00:15
1
0
***
***
Ramp
Fixed value
08.03.2015 05:05:06
Entry menu “Fan setpoint”.
A fan speed value is shown. Enter the desired value
with the operating button.
Setting range: 40 % up to 100 %
Press the “Ok” button to confirm.
..\ Fan setpoint
1
00
[%]
1
Pos1 End Ok 0 2 3 4 5 6 7 8 9 ,
Close Ok
When entering a value outside the setting range, the message “invalid value” appears. Press the operat-
ing button to confirm with “Ok” and repeat the entry with a correct value.
