Biolight Meditech M800 - Page 21

Handheld monitor user’s manual
Chapter 1-10
current SpO
2
value and its upper and lower alarm limits.
3. PR parameter area: The values shown in the area are
current PR value and its upper and lower alarm limits.
1.3.3 ECG Waveform Display Mode
Fig 1-6 ECG Waveform Display Mode
1. ECG waveform display area: Waveform shown in the
area is current ECG waveform.
2. SpO
2
parameter area: The values shown in the area are
current SpO
2
value and its upper and lower alarm limits.
3. HR parameter area: The values shown in the area are
current HR value and its upper and lower alarm limits.
1
2
3
