24 | Chapter 4: Instrument Qualification
Noise Test (Dark Air, Flash On)
Channel: Ref Meas
Noise Max: 5392 16857
Noise Min: 5392 16855
Noise Delta: 0 2
Wavelength 1: 200nm
Cal Data: Rst: 2 Gain: 1.07 Rst/Gain: 1.867
Test Data: Rst: 2 Gain: 1.12 Rst/Gain: 1.781
Channel: Ref Meas
Total Air: 14869 43719
Dark Air (On): 5390 2399
Signal Air: 9479 41320
Wavelength 2: 352nm
Cal Data: Rst: 4 Gain: 1.94 Rst/Gain: 2.062
Test Data: Rst: 4 Gain: 2.08 Rst/Gain: 1.921
Channel: Ref Meas
Total Air: 8944 45824
Dark Air (On): 5391 4411
Signal Air: 3553 41413
Wavelength 3: 620nm
Cal Data: Rst: 2 Gain: 1.97 Rst/Gain: 1.015
Test Data: Rst: 2 Gain: 1.96 Rst/Gain: 1.023
Channel: Ref Meas
Total Air: 9165 45154
Dark Air (On): 5390 4140
Signal Air: 3775 41014
Wavelength 4: 790nm
Cal Data: Rst: 1 Gain: 1.38 Rst/Gain: 0.722
Test Data: Rst: 1 Gain: 1.36 Rst/Gain: 0.734
Channel: Ref Meas
Total Air: 11031 43909
Dark Air (On): 5388 2890
Signal Air: 5643 41019
Wavelength 5: 860nm
Cal Data: Rst: 1 Gain: 1.94 Rst/Gain: 0.515
Test Data: Rst: 1 Gain: 1.94 Rst/Gain: 0.515
Channel: Ref Meas
Total Air: 9394 45433
Dark Air (On): 5389 4098
Signal Air: 4005 41335
Wavelength 6: 962nm
Cal Data: Rst: 1 Gain: 2.12 Rst/Gain: 0.472
Test Data: Rst: 1 Gain: 2.13 Rst/Gain: 0.469
Channel: Ref Meas
Total Air: 9033 45624
Dark Air (On): 5389 4503
Signal Air: 3644 41121
TEST SENSOR
Cal 13869
Self-Test 13868
Delta -1
AUTOCAL ANALYSIS
Upper Left Corner: x = 287 y =15615
Lower Left Corner: x = 279 y =21835
Lower Right Corner: x = 10034 y =21851
Upper Right Corner: x = 10045 y =158630
Delta 1: 287 - 279 = +8
