Page #68 background imageLoading...
Page #68 background image
50 | Appendix A: Specifications
General Specifications
Microplates
The Epoch accommodates standard 6-, 12-, 24-, 48-, 96-, and 384-well microplates
with 128 x 86 mm geometry; Terasaki microplates; up to 8 BioCells; and the BioTek
Take3 Multi-Volume Plate
Hardware & Environmental
Light Source
Xenon flash light source, 10W maximum average power, lamp
life 1 billion flashes (not user-changeable)
Dimensions
12.5" D x 12" W x 7.7" H
31.8 cm D x 30.5 cm W x 19.6 cm H
Weight < 15 lbs. (6.804 kg) (without power supply)
Environment
Operational temperature 18ºC to 40°C (65ºF–104ºF)
Humidity 10% to 85% relative humidity (non-condensing)
Power Supply
24-volt external power supply compatible with 100–240 V~;
+/- 10% @50–60 Hz
Power Consumption < 40W maximum
Read Specifications
The actual plate read time and accuracy are dependent on the method of reading:
Normal mode is the slowest of the two available modes. After positioning
the well over the beam, the instrument waits however long the user has
defined the delay (0–2550 ms) before taking the measurement (eight-flash
data collection).
The longer the delay, the more completely the fluids in the wells
settle.
Sweep mode is the fastest mode. The plate carrier sweeps each row past
the optics channel without stopping and collects data with a single flash at
each well as it goes by.
The following read times are based on a single or dual wavelength measurement.
Actual reading speeds may vary, depending upon the reading wavelength
selected. Each wavelength has a unique location within the monochromator, and
the different locations require varying amounts of time to position.
BioTek Instruments, Inc.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Biotek Epoch and is the answer not in the manual?

Biotek Epoch Specifications

General IconGeneral
TypeMicroplate Spectrophotometer
Wavelength Range200 - 999 nm
Light SourceXenon flash lamp
Power Requirements100 - 240 VAC, 50/60 Hz
Wavelength Repeatability+/- 0.2 nm
Absorbance Range0-4.0 OD
Plate Types6- to 384-well microplates
ShakingLinear, orbital
Detection ModesAbsorbance
SoftwareGen5
Bandwidth5 nm
ConnectivityUSB
