Automated Operation
B-9
Advanced Mode
Advanced Mode consists of manually configuring the FlightHawk-AV parameters
to perform measurements.
Prior to using the FlightHawk-AV in advanced mode you should familiarize
yourself with the basic operation of the unit.
Chapter 2
covers the basic
operation of the device, including changing measurement frequencies, selecting
mode of operation, number of data points to collect, displaying multiple traces,
and changing the scale of the displayed data. See
"FlightHawk-AV Basic
Operation" on page 5
.
Perform the following steps to use advanced mode.
Note: Prior to using the FlightHawk-AV in this mode a calibration
should be performed.
1. Prior to making any measurements in the advanced mode perform a
Calibration. See
"Calibration" on page 28
.
2. Select the type of measurement you wish to make:
a. Match Measurement (VSWR)
See
"Measure Match Mode" on page 29
for a detailed
explanation of this mode.
b. Cable Loss
This is a type of Match Measurement, see
"Cable Loss
Measurement" on page 31
for a detailed explanation of this
mode.
c. Fault Location /Distance to Fault (DTF)
See
"Fault Location Mode" on page 33
for a detailed explanation
of this mode.
d. RF Power Measurement
See
"RF Power Measurement" on page 48
for a detailed
explanation of this mode.
