2-12 Drawer kick-out connector pin
This defines the number of drawer kick-out connector pin.
Available settings are as follows.
Drawer kick-out connector pin 2
Drawer kick-out connector pin 5
2-13 Drawer open level
This defines the type of cash drawer
Available settings are as follows.
BXL_CASHDRAWER_OPENLEVEL_LOW
If Cash drawer is open,
Drawer kick-out connector
pin 3 is LOW
BXL_CASHDRAWER_OPENLEVEL_HIGH
If Cash drawer is open,
Drawer kick-out connector
pin 3 is HIGH
2-14 Model ID
This defines the type of printer.
Available settings are as follows.
BXL_MODEL_ID_SRP350plusII
BXL_MODEL_ID_SRP352plusII
2-15 Connection Class
When the method named 'didFindPrinter' is called,
This value is updated to connectionClass in BXPrinter class
Refer to 6-2-3 didFindPrinter
BXL_CONNECTIONCLASS_ETHERNET
