BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 15 -
4. BXPrinter Class Reference
Inherits from
NSObject
Confirms to
Framework
BXPrinter.a
[Availability]
iOS 4.3 and later
Declared
BXPrinterObject.h
4-1 Overview
BXPrinter Class contains the information of control target printer (name / network address /
port).
4-2 Properties
4-2-1 name
Printer name
@property(readonly) NSString * name
[Discussion]
Printer name is saved automatically by collecting information from the connected printer.
[Availability]
SDK 0.6.0 and later
4-2-2 address
Network address of printer
@property(readwrite) NSString * address
[Discussion]
Network address of the printer should be assigned first before connection.
[Availability]
SDK 0.6.0 and later
4-2-3 port
Network port of printer
@property(readwrite) unsigned short port
[Discussion]
Network port of the printer should be assigned first before connection.
[Availability]
SDK 0.6.0 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
