BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 34 -
5-3-28 downloadNVImage (Normal)
Download the image data to the designated address in NV area.
[Function prototype]
- (long)downloadNVImage:(int)address
withImage:(UIImage *)image
[Parameters]
address
Image address in the range of 0 ~ 99. If there is an image saved for the
corresponding address, the existing image is replaced by a new image.
images
Download target image object
[Return Value]
Refer to 2-16 Result Code
[Discussion]
When the width of the image is wider than the width of printer, the image is resized
automatically.
The width value is set to BXL_WIDTH_FULL and the image data processed with 1050 of
level, 50% of brightness and error diffusion algorithm enable settings is downloaded.
[Availability]
SDK 1.0.0 and later
5-3-29 printNVImage
Print the image data to the designated address in NV area다.
[Function prototype]
- (long)printNVImage:(int)address
[Parameters]
address
Image address in the range of 0 ~ 9
[Return Value]
Refer to 2-16 Result Code
[Discussion]
Image is not printed if image does not exist in the corresponding address.
[Availability]
SDK 1.0.0 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
