BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 21 -
5-2-16 drawerOpenLevel
@property(assign) int drawerOpenLevel
[Discussion]
Refer to 2-13 Drawer open level
[Availability]
SDK 3.0.1 and later
5-3 Instance Methods
5-3-1 getInstance
Method to obtain the BXPrinterController class instance
[Function prototype]
- (BXPrinterController)getInstance
[Return Value]
BXPrinterController class is created and returned automatically when this method is
called first time, and the existing BXPrinterController class is returned from the next time.
[Discussion]
Since BXPrinterController class uses only one instance in one process, user should
obtain and use it using this method instead of creating it.
[Availability]
SDK 0.8.0 and later
5-3-2 open
Initialization task for using BXPrinterController class (memory allocation and background
thread operation)
[Function prototype]
- (void)open
[Discussion]
- It should be called before calling main delegate of applications like
(void)applicationDidBecomeActive:(UIApplication *) application.
[Availability]
SDK 0.6.0 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
