BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 18 -
5-2-4 lookupDuration
Printer lookup time (unit: second)
@property(readwrite) CGFloat lookupDuration
[Discussion]
It could be a fractional number such as 0.5.
[Availability]
SDK 0.6.0 and later
5-2-5 lookupCount
Number of repeat on signal transmission for printer search
@property(readwrite) unsigned lookupCount
[Discussion]
Default value is set to 1. When it is set to a number bigger than 1, the printer search
signal transmission is repeated by this number at intervals of 0.2 seconds.
[Availability]
SDK 0.6.0 and later
5-2-6 alignment
Horizontal alignment setting
@property(readwrite) int alignment
[Discussion]
Default value is set to left alignment, and this setting affects all output printing including
text and bar code.
[Availability]
SDK 0.8.0 and later
5-2-7 attribute
Text printing property
@property(readwrite) int attribute
[Discussion]
Refer to 2-5 Text Attribute
[Availability]
SDK 0.8.0 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
