BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 20 -
5-2-12 state
Printer state code
This value is updated when checkPrinter method of BXPrinterController is called.
@property(readonly) long state
[Discussion]
Refer to 2-10 State
[Availability]
SDK 0.6.0 and later
5-2-13 power
@property(readonly) long state
[Discussion]
Refer to 2-9 Power
[Availability]
SDK 0.6.0 and later
5-2-14 AutoConnection
@property(assign) int AutoConnection
[Discussion]
Refer to 2-11 Connection Control
[Availability]
SDK 2.0.2 and later
<Note>
※ Printer connection is controlled automatically without using connect/disconnect
function in the automatic connection mode.
※ Consecutive use of printText function may slow down the printing speed because
most functions have a connect/disconnect job at the beginning and end of it.
Use the manual connection mode to address this issue.
5-2-15 drawerPin
@property(assign) int drawerPin
[Discussion]
Refer to 2-12 Drawer kick-out connector pin.
[Availability]
SDK 3.0.1 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
