BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 16 -
4-2-4 modelStr
Model name of printer
Name is provided by the firmware, and it is _SRP-350II in case of SRP-350II printer.
@property(readwrite) NSString * modelStr
[Discussion]
This value is updated by the checkPrinter method of BXPrinterController.
[Availability]
SDK 0.8.0 and later
4-2-5 versionStr
Firmware version of printer
Version name is provided by firmware, and it is in the form of _V01.00 STOB 040711.
@property(readwrite) NSString * versionStr
[Discussion]
This value is updated by the checkPrinter method of BXPrinterController.
[Availability]
SDK 0.8.0 and later
4-2-6 connectionClass
Printer interface type.
This value represents the way that the printer is connected.
Refer 2-15 Connection Class.
@property(readwrite) unsigned short * connectionClass
[Availability]
SDK 3.0.3 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
