BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 19 -
5-2-8 textSize
Size of the printed text
@property(readwrite) int textSize
[Discussion]
Refer to 2-4 Text Size
[Availability]
SDK 0.6.0 and later
5-2-9 characterSet
Defines the code page of printer
@property(readwrite) CGFloat lookupDuration
[Discussion]
Refer to 2-1 Character Set
Default value is set to BXL_CS_437.
[Availability]
SDK 0.6.0 and later
5-2-10 internationalCharacterSet
@property(readwrite) char internationalCharacterSet
[Discussion]
Refer to 2-2 International Character Set. Default value is set to BXL_CS_437.
[Availability]
SDK 0.6.0 and later
5-2-11 textEncoding
Type of the text Encoding.
@property(readwrite) long textEncoding
[Discussion]
Refer to NSStringEncoding in NSString.h
[Availability]
SDK 3.0.2 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
