BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 17 -
5. BXPrinterController Class Reference
Inherits from
NSObject
Confirms to
Framework
BXPrinter.a
[Availability]
iOS 4.3 and later
Declared
BXPrinter.h
5-1 Overview
BXPrinterController Class is the main object for printer control.
5-2 Properties
5-2-1 version
SDK version
@property(readonly) NSString * version
[Discussion]
It is a string in the form of “1.0.0” and it is read only.
[Availability]
SDK 0.6.0 and later
5-2-2 delegate
Assign the object to apply BXPrinterControlDelegate method
@property(readwrite) id<BXPrinterControlDelegate> delegate
[Availability]
SDK 0.6.0 and later
5-2-3 target
Control target printer object
@property(readwrite) BXPrinter * target
[Discussion]
It is a control target printer object and should be assigned before starting printer control.
[Availability]
SDK 0.6.0 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
