BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 32 -
5-3-26 nvImageList
Read the list of image addresses saved in NV area.
[Function prototype]
- (long)nvImageList:(NSArray **)images
[Parameters]
images
Address list is provided. Each address is saved in the form of NSNumber *. The
images are provided in the form of autorelease, and developers do not have to
release it explicitly.
[Return Value]
Refer to 2-16 Result Code
[Discussion]
<Example >
NSArray *images;
[[BXPrinterController getInstance()] nvImageList:&images];
for( NSNumber *n in images)
{
NSLog(@”%d”, [NSNumber intValue]);
}
[Availability]
SDK 1.0.0 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
