BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 38 -
6. BXPrinterControllerDelegate Protocol Reference
Inherits from
NSObject
Confirms to
Framework
BXPrinter.a
[Availability]
iOS 4.3 and later
Declared
BXPrinteControlDelegater.h
6-1 Overview
This receives events occurring in the BXPrinterController class.
6-2 Instance Methods
6-2-1 didStart
It is called when class starts to be used using open method of BXPrinterController.
It is called after printer connection is completed.
[Function prototype]
- (void) didStart
[Parameters]
controller
BXPrinterController object that generates events
[Discussion]
It can be used to indicate the beginning of the use of printer class to users.
[Availability]
SDK 0.6.0 and later
6-2-2 didStop
It is called when class use is stopped using open method of BXPrinterController.
[Function prototype]
- (void) didStop
[Parameters]
controller
BXPrinterController object that generates events
[Discussion]
It can be used to indicate the termination of the use of printer class.
[Availability]
SDK 0.6.0 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
