BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 41 -
6-2-9 didBeBrokenConnection
This method is called when the connection to printer is broken.
[Function prototype]
- (void)didBeBrokenConnection:(BXPrinterController *)controller
withError:(NSError *)error
[Parameters]
controller
BXPrinterController object that generates events
error
Information of cause of failure
[Discussion]
This is not called when user breaks the connection by calling the close method of
BXPrinterController explicitly. This method is called only when the connection is
interrupted by external problem other than user intervention.
Refer to the target property of BXPrinterController for the information of target printer.
[Availability]
SDK 0.6.0 and later
6-2-10 msrArrived
This method is called when MSR data arrives correctly in MSR Read mode.
[Function prototype]
- (void)msrArrived:(BXPrinterController *)controller
track:(NSNumber *)track
[Parameters]
controller
BXPrinterController object that generates events
track
Track number 1 ~ 3 for MSR data
[Discussion]
After this method is called, the MSR data of the corresponding track can be obtained
through the getTrack: method of BXPrinterController.
[Availability]
SDK 0.6.0 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
