BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 25 -
5-3-11 lineFeed
Perform line feed
[Function prototype]
- (void)linefeed:(int)lines
[Parameters]
lines
Number of lines to advance
[Return Value]
Refer to 2-16 Result Code
[Availability]
SDK 0.6.0 and later
5-3-12 nextPrintPos
Feed the paper to the beginning of the next label paper.
[Function prototype]
- (long)nextPrintPos
[Return Value]
Refer to 2-16 Result Code
[Discussion]
This method works only when in label mode.
[Availability]
SDK 0.6.0 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
