BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 24 -
5-3-9 printText
Print text.
No operation takes place when there is no connected printer.
[Function prototype]
- (long)printText:(NSString *)string
[Parameters]
string
Unicode data with null terminator. Print target text string
[Return Value]
Refer to 2-16 Result Code
[Discussion]
Tex alignment property should be set in advance.
[Availability]
SDK 0.6.0 and later
5-3-10 printBox
Print box shape text.
No action takes place if no printer is connected.
[Function prototype]
(long)printText:(int)width height: (int)height;
[Parameters]
int
Specify the width of the box.
1 == width equivalent to that of one character
int
Specify the length of the box.
1 == length equivalent to that of one character
[Return Value]
Refer to 2-16 Result Code
[Discussion]
Alignment and properties of the text should be defined in advance.
[Availability]
SDK 3.0.3 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
