BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 39 -
6-2-3 didFindPrinter
This method is called for each individual printer when a printer is discovered from the
same network.
[Function prototype]
- (void)didFindPrinter:(BXPrinterController *)controller
printer:(BXPrinter *)printer
[Parameters]
controller
BXPrinterController object that generates events
printer
Information of discovered printer
[Discussion]
If same printer responds multiple time during the printer lookup process, this method is
called only once the first time.
[Availability]
SDK 0.6.0 and late
6-2-4 didConnect
This method is called when connection to printer finished.
[Function prototype]
- (void)didConnect:(BXPrinterController *)controller
[Discussion]
If you need to have more information about target printers, please refer to target
properties in BXLPrinterController.
[Availability]
SDK 2.0.2 and later
6-2-5 didNotConnect
This method is called when connection to printer cannot be made.
[Function prototype]
- (void)didNotConnect:(BXPrinterController *)controller
withError:(NSError *)error
[Parameters]
controller
BXPrinterController object that generates events
error
Information of cause of failure
[Discussion]
This can be used when there is error during printer connection stage.
[Availability]
SDK 0.6.0 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
