BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 22 -
5-3-3 close
Resources are de-allocated for stopping or terminating the use of BXPrinterController
class.
[Discussion]
- It should be called before calling main delegate of applications like
(void)applicationWillResignActive:(UIApplication *) application.
When close method is not called and applications using BXPrinterController are running
in the background, simultaneous use of BXPrinterController by other applications could
be restricted.
[Availability]
SDK 0.6.0 and later
5-3-4 lookup
Printers in the same WiFi network where iPhone is connected are searched.
[Function prototype]
- (void)lookup
[Discussion]
Stat/End of search and searched printers can be obtained through BXPrinter
ControlDelegate.
Each iPhone has two network adaptors including 3G and WiFi networks, and the lookup
method searches WiFi only.
No operation takes place when there is no connected WiFi.
[Availability]
SDK 0.6.0 and later
5-3-5 selectTarget
Initialization task for object of specified target.
[Function prototype]
- (long)selectTarget
- (long)selectTarget : (int) modelID
[Parameters]
modelID
- Select to type of printer.
- If you were not input, This is allocated automatically.
Refer to 2-14 Model ID.
[Return Value]
Refer to 2-16 Result Code
[Discussion]
Target of BXPrininterController property should be set in advance.
[Availability]
SDK 2.0.2 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
