BIXOLON SRP-F310 Reference Guide

POS Printer
Rev. 2.00
- 35 -
5-3-30 removeNVImage
Delete image data from the designated address in NV area.
[Function prototype]
- (long)removeNVImage:(int)address
[Parameters]
address
Image address in the range of 0 ~ 99
[Return Value]
Refer to 2-16 Result Code
[Discussion]
No action takes place if image does not exist in the corresponding address
[Availability]
SDK 1.0.0 and later
5-3-31 removeAllNVImages
Delete all image data from the designated address in NV area.
[Function prototype]
- (long)removeAllNVImages
[Return Value]
Refer to 2-16 Result Code
[Availability]
SDK 1.0.0 and later
5-3-32 openDrawer
Open to the Cash Drawer.
[Function prototype]
- (long)openDrawer
[Return Value]
Refer to 2-16 Result Code
[Availability]
SDK 3.0.0 and later

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
