104
Figure 3.55 – Utility Menu Screen 2
Table 3.52 – Utility System Menu 3
Option
Setting
Description
Update
firmware
Update the firmware of the
oscilloscope using a USB flash Drive.
Pass/Fail
Press this button to enter the “Pass/Fail
menu”.
Record
Press this button to enter the
waveform record menu.
Next Page
Page 3/4
Press this button to enter fourth page.
